-810443.jpg) |
| The comparison of these two images is indicative of the types of image files I made to compare the full frame 45.44mp Nikon file to an upscaled (to same pixel dimension on the long side) Micro 4/3 20.11mp file from the OM-1 Mark II. The is the full image from the Nikon Z8. It is 45.44mp. (click to enlarge) |
-3.jpg) |
| This is the upscaled 20.11mp image from from the OM-1 Mark II. It has been upscaled to the same linear dimension as the long side of the Nikon file. It is 51.1mp. The difference in file size (45.44mp vs. 51.1mp) is due to the difference in the format—2X3 v. 4X3. The Micro4/3 image has more pixels on the short side of the file. |
On occasion, because we aren’t in the best position, or don't have the right gear with us, to ‘get it right in the camera’ we may need to crop our images significantly. Also, possibly, we want to make a very large print. Sometimes, maybe both. In the past, those two things may not turn out to your satisfaction if one’s camera sensor didn’t have a large number of pixels. I own and use a 20mp OM-1 Mark II as well as a 46mp Nikon Z8. Because sensor size and pixel count are so different in the two cameras, it got me to wondering a couple of things.
The first question I had for myself was, “Can upscaling an OM-1 Mark II 20mp file favorably compare in fine detail and sharpness to a native Nikon Z8 46mp image file?”
The second question I had for myself was, “How does using the 50mp High Resolution Handheld feature in an OM-1 Mark II compare to a native 46mp Nikon Z8 file as well as to an upscaled 20mp > 46mp from the OM-1?”
The only way for me to find out and satisfy my curiosity was to conduct some simple, somewhat non-scientific, tests. Practical comparisons.
I made several identical image files (considering the differences in sensor size and shape) with my OM-1 Mark II and Nikon Z8. The images included vegetation such as grass, leaves, flower blossoms and small bare tree limbs as well as some letters, numbers and structures. I wanted a variety of subjects for comparison. These are kinds of things I regularly photograph so using the same subject matter for comparison sake makes sense.
I had the OM 12-40mm f/2.8 II Pro lens attached to the OM-1 Mark II and the 24-120mm f/4 lens attached to the Z8. Both are excellent lenses. They are my "go to" lenses on both cameras. My intention was to make the tests with lenses I use regularly, not some exotic primes. In other words, again, a practical test with practical choices.
I made raw images at f/4 and f/5.6 with the OM-1 and f/8 and f/11 with the Nikon. From my prior testing I consider those apertures the best for my copy of each lens. I shot images at the full frame equivalent of 35mm, 50mm and 80mm. All images were handheld and manually focused using a 10X magnification. Using autofocus, more or less, tests your autofocus accuracy and I wanted to remove that variable from the test. Both cameras were set for ISO 200, which is the native ISO of the OM. I handheld the exposures because that is the way I normally photograph. I rarely use a tripod due to the excellent image stabilization in both of these cameras. Again, a practical test using the cameras how I normally use them.
Importing the files into Lightroom, I made some initial edits in the files from both cameras in brightness, color balance, highlights and shadows. For the Nikon files, I also added some texture, clarity and adjusted the sharpening as I normally would. At this point I did not make any adjustments in texture or clarity in the OM files. Additionally, I zeroed out the default sharpening. Those adjustments would be applied to the OM files after they returned from Topaz Gigapixel and Topaz Photo AI. I always send files to the Topaz plug-ins without any sharpening, clarity or texture applied. I could have sent the OM files to Topaz as raw files but, in this test, didn’t. I just didn’t think of it. I may go back and send a file as a raw file to see if I can detect any differences. If I do, I’ll update this post.
I then sent the OM files to Topaz Gigapixel AI v.8 as well as a couple to Topaz Photo AI as I also wanted to know if one performed better than the other. In Gigapixel AI I set the upscaling to the same pixel dimension as the long side of the Nikon files—8256 pixels. However, remember the two cameras’ file are different shaped rectangles—the Nikon is a 2X3 ratio and the OM 4X3 ratio so the final image files would differ in total megapixels. I then returned the OM files to Lightroom, added the same amount of texture and clarity to the newly upscaled OM files as I did with the Nikon files but did not add any additional sharpening as that was handled in Gigapixel.
So, what did I find? I'll describe it to you the best I can. I've included a number of 100% crops from both cameras. I don't know how well you will be able to see any differences after Blogger compresses them. Here they are with a description below.
-810443.jpg) |
| Approximately a 100% crop from the Nikon Z8 file. (click to enlarge) |
-3.jpg) |
| The same from the OM-1 Mark II upscaled file. (click to enlarge) |
-810443.jpg) |
| Nikon Z8 file. I don't know if you can see them in Blogger, but notice the tiny antenna shafts above the building's dormers. Also notice the birds and antenna shafts on the roof on the right. (click to enlarge) |
-3.jpg) |
| OM-1 Mark II upscaled file. Notice the same are visible here also. (click to enlarge) |
-810443.jpg) |
| Nikon Z8 file. Notice the tiny bare branches above the tree line on the left. (click to enlarge) |
-3.jpg) |
| OM-1 Mark II file. Notice the same fine, tiny branches are visible as well in the upscaled file. Also, notice the letters on the small size attached to the railings are not quite reproduced as well as the native Nikon file. (click to enlarge) |
-810443.jpg) |
| Nikon Z8 file. (click to enlarge) |
-3.jpg) |
| OM-1 Mark II upscaled file. (click to enlarge) |
The answers from my testing are…..drumroll, please….The differences I could see in detail between the upscaled 20mp > 46mp OM-1 image file and the native Nikon Z8 native 46mp image file are so small and insignificant that I can safely say they are essentially identical. I had to examine the images so closely and only found a couple of differences in tiny detail. The differences are sparse and so minor that I say they are inconsequential.
I could see the same small bare branches in distant trees. I could see the same small antennas on top of the buildings. I could see the same birds on the roof. I could see the same amount of detail in the grasses. I could see the same amount of detail in the pine branch, pine needles and small pine cones in the upper left of the frame. I could read the names on the construction equipment and the sign on the front of the red building. In those regards, I didn't see any differences at all.
I saw no difference in sharpness.
The biggest difference is in the two cameras rendition of color. Nikon and OM’s color rendition is very different—or more properly said, Lightroom’s interpretation of color is very different. I did my best to match the color rendition of both brand's files to match pretty closely.
Another difference I found was that there was some moiré in some of the tiny spindles of the railings along the front of the buildings. A bit of moiré was also found in some of the roof tiles on the red building above the words "Smithfield" across the front. That small amount of moiré can be negated in Lightroom so that didn't bother me. The other difference I saw was in the Keller/Williams sign along the railing in the left center of the image. The upscaled version did not reproduce the letters as clearly as the native Nikon file. A very minor difference. I did try using the "Preserve Text" in Photo AI but saw little difference.
When testing both Photo AI and Gigapixel, I didn't find a significant difference but I think the latest version (8.0) of Gigapixel AI did just a bit better job in retaining extremely fine detail.
All of the differences I just pointed out are so small and, in my view, insignificant. I had to look at the files with the proverbial 'fine tooth comb' to find any differences.
Now this is interesting. Technically, we know that a 20mp file doesn't capture as much fine detail as a native 46mp file. When upscaling the 20mp file to 46mp, more fine detail is not added nor created. The fine detail is just being enlarged through interpolation. That said, I could not find any additional fine detail in the Nikon file than I could see in the upscaled 20mp file. That was a surprise considering the 46mp files should capture more fine detail. That tells me that having those extra pixels is a 'fool's errand.' If I can't see any differences in fine detail between a 20mp file upscaled to a 46mp and a native 46mp file, how large a print would I have to make the 46mp file in order to actually see a difference? Again, this is not a scientific examination conducted with a microscope but a practical test to satisfy my curiosity of what 'practical' differences there are. My answer to me: Little to none.
As far as the 50mp Handheld High Resolution feature in the OM-1, well, it didn’t do nearly as well as the upscaled file. Not even close. If it is ever necessary to enlarge a 20mp OM file or the need to crop in significantly arises, the upscaled file is much better in detail and sharpness. Topaz software does an amazing job.
In the future, I will feel very comfortable using my 20mp OM-1 and superb Olympus and OM lenses and no longer worry that I'm missing out on something or at a disadvantage in sharpness and fine detail that my full frame Nikon files exhibit. If I ever need to crop in significantly or make really big enlargements, I know I can do it with little or no penalty. I call that piece of mind.
For those of you who still carry the mantra that Micro4/3 can’t possibly be any good, you need to go back to photo school and see how good the technology today really is.
My final word is: Don't take my word for it. Conduct your own experiments to satisfy yourself. I try to be very careful as to how I set up tests so they are practical and not a laboratory exercise, reduce the number of variables, are repeatable, and provide answers to my own questions. That way, I can know of what my cameras and lenses are capable.
Join me over at my website, https://www.dennismook.com.
Thanks for looking. Enjoy!
Dennis A. Mook
